1. Lateral movement The lateral movement allows the trimming to be adjusted to the appropriate width. The minimum trimming width of the toilet paper machine is even 20mm per side. If the trimming is too narrow, the process of entering the straw will become difficult and the paper may break.
2. Longitudinal movement The longitudinal movement is the movement of the parent roll in the direction of the paper web. It is possible to balance the tension error of the paper web on the driving side and the operating side by moving the rewinding frame on the operating side of the toilet paper machine forward or backward. When making adjustments, it is necessary to observe the condition of the paper web*.
3. The independent creeping of unloading paper The independent creeping of unloading paper is used when you only want to roll the parent roll in the unwinding area, and when the parent roll is crawling independently, you can make some preparations, such as paper threading or paper splicing. Use the control switch to turn on the toilet paper machine to crawl independently. The rolling direction of the independent crawling is selected by the potentiometer. The center position of the potentiometer is the zero point of the crawling. Scroll clockwise.
