Summary:
Triple layer BOM felt includes 1 +2, 2 +1 and 1 +1 +1 composite BOM felt. These felts can be applied to more than 200kN/m linear pressure and possess good flexibility; good permeability and can effectively eliminate many kinds of marks, excellent size stability, long life performance etc. Applying to high speed of the paper machine for suction complex press, large diameter nip roll press and shoe press and can produce high-grade newsprint, write paper, paperboard etc.
Triple Layer BOM Felt | 1+2 Layer BOM Felt | Tri-layer BOM For Large Roll Press |
2+1 Layer BOM Felt | Tri-layer BOM For Shoe Press | |
1+1+1 Layer BOM Felt | Tri-layer BOM For Hot Press |
Application：
1. Paper Machine：Medium/ high Velocity paper machine of Multi- cylinder,Fourdrinier,Superposition Wire,Vacuum Composite Press, Large Diameter Roll Press,Shoe Press etc
2.Paper Machine Velocity：≤1000m/min
3.Paper:≥40g/m2 newsprint,write paper,high-grade board paper etc.
4. NIP:≥200kN/m
Main technical data
1.Felt GSM：1450~1750g/m2
2.GSM Tolerance：≤±4%
3.Air Permeability：40~90cfm
4.Tensile Strength：≥4500N/5cm
5.Elongation Percentage：≤0.6%
6.Width Variation：≤±2cm
Triple Layer BOM Felt | |||||
No | Product No. | GSM | Structure style | Application | Note |
1 | 47601 | 1450—1550 | Triple layer domestic material | Big roll press, high-grade write paper, newsprint, pack paper, corrugating, kraft paper etc | Good filtration,good flexibility, flat surface, long life performance |
2 | 47602 | 1500—1700 | Triple layer domestic material | Big roll press, high-grade coating white board, paperboard, corrugating, kraft paper etc | Good filtration, good flexibility, flat surface, long life performance |
3 | 47621 | 1450—1550 | Triple layer import material | Big roll press, shoe press,high-grade write paper, newsprint, package paper, corrugating, kraft paper etc | High line press, big vacuum, anti wear-out, good flexibility, flat surface, long life performance |
4 | 47622 | 1500—1700 | Triple layer import material | Big roll press, shoe press, high-grade coating white board, paperboard etc | High line press, big vacuum, anti wear-out, good flexibility, flat surface, long life performance |
5 | 47629 | 1600—1900 | Triple layer import material | Big roll press, shoe press, high-grade coating white board, paperboard etc | High line press, big vacuum, anti wear-out, good flexibility, flat surface, long life performance |
